Ratiometric and Single Wavelength Imaging SystemThe InCyt-Im line of imaging systems utilize sensitive videoeameras to capture changes in fluorescence intensity in each pixel in the microscope's field of video. Thus, multipe objects can be indepently monitored over time. |
 |
 |
Basic IM >> |
Standard IM >> |
High Speed IM >> |
||||
| Speed of data acquisition |
1.5 ratiometric images per second 15 single-wavelength images per second |
4 ratiometric points per second |
20 ratiometric points per second |
|||
| Camera | Basler Scout Monochrome Integrating 12-bit CCD Image Resolution:640 x 480 pixels |
DVC 340M Monochrome Integrating 12-bit CCD with Binning Capabilities Image Resolution:640 x 480 |
DVC 340M Monochrome Integrating 12-bit CCD with Binning Capabilities Image Resolution:640 x 480 |
|||
| Microscope | Accuscope 3032 Inverted Fluorescence Microscope |
Nikon TS100F Inverted Fluorescence Microscope |
Nikon TS100F Inverted Fluorescence Microscope |
|||
| Filter changer | Tofra Wheel Filter Changer | Sutter Wheel Filter Changer | Sutter DG5 fast Wavelength Changer with built-in Xenon arc lamp | |||
| Light source | Sutter LB-LS17 175 watt Xenon arc lamp for both UV and visible light excitation. | Sutter LB-LS17 175 watt Xenon arc lamp for both UV and visible light excitation. |
